Vox AC15 Hand-Wired 1x12 Guitar Amp Combo (AC15HW1) - Limited

There may never have been an amp boasting such a lofty and pure sound in the entire history of VOX. The VOX Hand-Wired Series relies on the painstaking technique of turret board hand-wiring – a method requiring a high level of skill and craftsmanship – is used, resulting in wiring that’s beautiful in its artistry, ensuring an efficient signal path with minimal loss and no restriction in amplitude. In the Hand-Wired Series, tubes, transformers, speakers, chassis, and custom parts all join together in an ideal state to deliver the richest and most powerful sonic experience – the ultimate amp. Not bound by tradition, the VOX Hand-Wired Series also provides a variety of new functions that keep pace with the needs of today’s artists. Offering a rich variety of tonal shadings and a broad model lineup, the enormous potential of the VOX Hand-Wired Series will reveal itself in any musical scenario.

Key Features and Product Highlights

• Hand-wired turret board construction
• Birch-ply cabinets featuring solid bracing and a natural high frequency diffuser
• All-tube design
• ECC83/12AX7 preamp tubes (x3)
• EL84 power tube quartet; (AC30 models); EL84 Duet (AC15 models)
• GZ34 rectifier (AC30 models); EZ81 rectifier (AC15 models)
• Fitted with matched Ruby Tubes that provide extended dynamic range
• Traditional VOX two-channel design.
• Top Boost and Normal. High and Low inputs for each channel
• The Normal channel provides an additional BRIGHT switch.
• The top boost channel provides a HOT/COOL switch to achieve even more gain
• Master Volume/BYPASS switch completely bypasses the Master Volume section
• OP mode switch cut the amp’s Output Power level in half
• Vintage fawn-colored vinyl, reminiscent of the 1960 classic AC30
• Choose either Celestion Alnico Blue or Celestion G12M Greenback
• VFS1 footswitch controlls the Top Boost channel's HOT/COOL switch
• A premium, custom-fit dust cover is included with every model

AC15HW1

Output Power: 15 Watts RMS into 8/16 Ohms
Tube Complement: Preamp: ECC83/12AX7 (x3), Power amp: EL84 (x2), Rectifier: EZ81
Speakers: 12” Celestion G12M Green Back (x1); 16 Ohm
Inputs:

NORMAL Channel Jacks: HIGH (x1); LOW (x1)
TOP BOOST Channel Jacks: HIGH (x1); LOW (x1)
FOOT SWITCH Jack

Outputs: External Speaker Jack, Extension Speaker Jack
Dimensions (W x D x H): 610 x 260 x 550 mm / 24.02 x 10.24 x 21.65 inches
Weight: 22.2 kg / 48.9 lbs.
Included items: Power cable, VFS1 footswitch, Dust cover

• Hand-wired turret board ensures efficient signal path
• 15W output with switchable speaker impedance
• All-tube design offers rich, powerful sound
• Features Celestion G12M Green Back speaker
• Includes VFS1 footswitch for easy control
• Vintage fawn vinyl design for classic appeal
• Master volume bypass switch for pure tone
• EZ81 rectifier for consistent performance
